LONGER Ray5 20W Laser Engraver Engraving Cutting Machine 375x375mm Quick Focus Wifi Control Real Power 24W 3.5inch Touch Screen
LONGER Ray5 20W Laser Engraver Cutting Machine 375x375mm Quick Focus Wifi Control Move Thermal Offline Motionless Eye Protection
Product parameters
Model Number: Ray5 20W
Output laser Power: 22-24W
Laser Technology: Dioser Technology
Working Area: 375x375 mm (14.76x14.76 inch)
Laser Wavelength: 450 - 460 nm
Focal Length: Fixed Focus-40mm
Laser Spot Size: 0.08x0.10mm
Laser Optical Output Power: 18 - 21 W
Power Max Consumption: 120W
Z Axis-Height Range : Up to 47mm
Fastest Working Speed: 10000mm/min
limit switches: Yes
Air assist interface: Yes
Engraver Output: DC12V / 5A
Engraver Input: AC 110-240V
Software: LaserGRBL & LightBurn
Connection: USB / TF Card / Wifi
Laser Engraver Size: 610 x 67 x 200 mm(24.02 x 26.38 x 7.87 inch)
Package Size: 621 x 347 x 127mm(24.45 x 13.66 x 5 inch)
Carving and cutting materials: Basswood, leather, ceramics, glass, stone, metal, etc
Cutting parameters one-pass:10mm basswood, 15mm pine, 8mm acrylic, 0.05mm stainless steel
20W Powerful Cutting
The 22-24W optical output laser modules largely boosts the cutting capacity of the Ray5.
It cuts through 25mm wood and 35mm acrylic by multiple passes,
and cut 0.002"/0.05mm stainless steel.
Higher Accuracy Cutting & 0.08*0.1mm² High Accuracy Laser Spot
The Ray5 is equipped with an ultra-fine 0.08 x 0.1mm focus point,
producing thinner lines, clearer texture, and more precise artwork .
More Productivity
More power leads to faster engraving and cutting, and a wider variety of materials that you can use.
Ideal for professional work, workshops, or factories .
Multi-Color Engraving
The 22-24W laser instantly oxidizes metal, bringing vibrant colors to fulfill your creative needs.
X/Y-axis Limit Switches
Limit switches can accurately locate the position of the laser module,
allowing for a safety feature where the Ray5 will trigger an alarm if it detects the laser is moving in the wrong direction.
Safety Measures
Installed Move/Thermal/Offline/Motionless/Eye Protections.
Laser Lens Protection
The 22-24W model is equipped with a replaceable lens and dust-proof hood which prevents smoke from polluting the lens.
Data Transfer Methods
Supports Wi-Fi, USB, APP and TF cards. The Ray5 is not limited to a physical computer connection.
